SYS8F600VGGA-8265U

Intel i5-8265U 处理器3.5" 嵌入式主板，带2HDMI/LVDS/3M.2，双GbE网口

· Intel i5-8265U 处理器 3.5" 嵌入式主板
· 支持DDR4-2400/2133MHz内存，最高到16GB
· 双 Intel 千兆网口
· 1 个 SATA3.0 , 6 个 串口 , 11 个USB
· 支持2HDMI/LVDS
· 支持独立三显
· DC12V输入









产品规格
Processor
CPU
Intel core 8th Gen i5-8265U CPU, 1.6GHz /4C/8T/15W
BGA1528
Chipset
SOC
BIOS
AMI UEFI
DRAM
Technology
DDR4-2400/2133MHz
Capacity
Up to  16GB
Socket
1 x 260-Pin SO-DIMM
Display
Graphics
Intel HD Graphics support DX11.1 和 OpenCL 1.2
Graphics Memory
Share System memory up to1.7GB SDRAM
LVDS
1, Max. resolution：1920x1200@60Hz
HDMI
2 x HDMI, Max. resolution：4096x2160@30Hz
Multi-Display
3 Independent display
LAN
2 x Intel GbE Controller (i211-AT+i219-LM)
Audio
Realtek ALC897 support Line-Out /Mic/Line-in
Watchdog
Software Programming 1~255s System Reset
Storage
SATA
1xSATA3.0
M.2(Key-M)
1 (PCIe/SATA 2242/2280)
RAID
N/A
I/O
Serial Port
6 x RS232（COM1 & COM6 support RS232/485）
USB
4 x USB3.0 + 7 x USB2.0
GPIO
4-In , 4-Out (5V/GND)
PS/2
N/A
TPM
Yes(built-in)
Expansion
Slot
M.2(Key-B)
4G+5G (3042/3052)
M.2(Key-E)
WIFI+BT(2230)
LED
HDD/PWR
Power
DC 12V
Form Factor
146mm x 105mm
Environment
Operation Temp& Humidity
-10~70℃/10~90%,non-condensing
Storage Temp& Humidity
-20~80℃/10~90%,non-condensing
Certification
EMC
CE / FCC
O.S
Whiskey Lake: Windows 10 64bit/Linux (Kernel 4.X)
订购信息
Model                                      Description
SYS8F600VGGA-8265U         Intel i5-8265U SBC, w/2HDMI/LVDS/2GbE/6COM/11USB/3M.2/HDA/DC12V
资料下载
Datasheet                                Manual

驱动下载
Drivers
Date
 Audio.zip
 2022-01-13
 Chipset.zip
 2022-01-13
 Display.zip
 2022-01-13
 LAN.zip
 2022-01-13
 ME.zip
 2022-01-13
 RST.zip
 2022-01-13
 SIO.zip
 2022-01-13
